FSI B21 Pedestrian Stumpgrinder Description
The newest balanced and compact stump grinder that may be used to remove any kind of tree stump is the B21.
The revolutionary Hill Hold System You no longer need to be concerned about your stump grinder rolling away from you as you climb the ramp. Transport up ramps, over steps or curbs, and over terrain is safe and simple thanks to a special braking mechanism. The stump cutter may be moved backwards safely and simply when the hill-hold mechanism is engaged without running the risk of the wheels rolling forward.
With the invention of a closed bearing housing, which is lubricated from the factory for more than 1000 hours of normal operation, there is no longer a need for daily maintenance. As a result, you are no longer need to consider daily bearing lubrication.
FSI B21 Pedestrian Stumpgrinder Specification
ENGINE
Engine size: 8.2 kW/11.1 hp
Engine type: Honda GX 390
Fuel type: Petrol
Fuel tank: 6.1 litre
Hours per tank: App. 3 hours
CUTTING HEAD
Cutting disc diameter: 370 mm
Tooth system: 3 x turnable
Tooth diameter: 20.5 mm
No of teeth: 8
Clutch: Centrifugal
Cutting disc drive: V belt system
Sweep: Manual
TRANSMISSION
Ground drive: Yes
Traction wheels: Yes
Steering wheels: ø365 x 100, 6 ply
Brakes: 2 independent brakes
CUTTING DIMENSIONS
Cutting height above ground: 300 mm
Cutting depth below ground: 200 mm
Cutting sweep width: 800 mm
Sweep speed: Manual
MEASUREMENTS
Length: 1800 mm
Width: 680 mm
Height: 1100 mm
Weight: 130 kg
